| Measurement items |
Cs, Cp, D (loss coefficient) |
| Measurement frequency |
120 Hz or 1kHz, Accuracy : ± 0.01% or less |
| Measurement signal level |
1 V or 500 mV, Accuracy : ± 10% ± 5mV
| CV 1 V : |
70 µ F range (1kHz)
700 µ F range (120Hz) |
| CV 0.5 V : |
170 µ F range (1kHz)
1.45 mF range (120Hz) | |
| Measurement range |
C : 0.9400 pF to 20.0000 mF (5-digit display), Accuracy : ± 0.1 %
D : 0.00001 to 1.99000, Accuracy : ± 0.0016 |
| Equivalent circuit mode |
Straight/parallel equivalent circuit mode, Auto/Manual |
| Measurement time |
Nominal 2 ms (1kHz, FAST) |
| Measurement speed |
FAST, NORMAL, SLOW |
| Trigger function |
Internal and external trigger sources |
| Other function |
Comparator, Audible buzzer, Printer (option) Bin (3504 only), Phase-synchronous function |
| Interface |
RS-232C and EXT I/O (standard) GP-IB (3504 only) |
| Display device |
LED |
| Power supply |
AC 100 V, 120 V, 220 V, or 240 V ± 10% (selectable),50/60 Hz, 100 VA max. |
| Dimensions and mass |
Approx. 260 H × 100 W × 220 D mm, 3.8 kg |
| Supplied accessories |
Power cord (1), spare fuse (1) |
|
|
